Radio Frequency, Microwave, Power and Compliance Components and Equipment

Since 1961, representing High Performance, Best in Class manufacturers of Radio Frequency/Microwave and AC/DC Power Components and Equipment for OEM and Test & Measurement applications.

Supporting Aerospace, Automotive, Commercial, Consumer, Educational, Industrial, Medical and Military markets

Featured Product Lines

AC Power Analyzers that compete against Yokagawa Instruments. They have a unique Dual Path capability. Read more »

SSA5000A Series

The SSA5000A spectrum analyzer series includes two models that provide fast spectrum analysis from 9 kHz to 13.6 or 26.5 GHz, a DANL of -165 dBm/Hz, low phase noise of 105 dBc/Hz, and feature a big 12-inch TouchScreen. These Analyzers are ideal in communications and IoT industry. The SSA5000A also fits well for RF component and transmitter evaluation. The options analog and digital modulation analysis (AMA / DMA) enable standard analog (AM, FM) and digital (ASK, FSK, PSK, MSK, QAM) demodulation and analysis. These help to speed up transmission debugging and troubleshooting. It intuitively measures EVM and other transmission quality factors and features Eye-diagram and constellation graphing modes.

The SSA5000A can also capture intermittent signals using the optional real-time (RTSA) mode. This feature has an analysis bandwidth of up to 40 MHz and is built to make transmission analysis of common protocols like Bluetooth and WLAN testing at IoT devices easier. In addition, the optional EMI feature delivers efficient interference and electromagnetic pre-compliance measurements. The platform is designed with expansion in mind allowing for field upgrades.

SSG5000S Series

The new SSG5000A RF/MW signal generator can output up to 20 GHz clean sine waves. The spectral purity, the low phase noise of -120 dBc/Hz, and power control make it ideal for use as a high-frequency LO in many applications like radar, quantum physics, and RF component verification. Communication modules can also be tested using the SSG5000A as the LO source and the Siglent SSG5000X-V as a baseband generator. For faster testing, the SSG5000A also provides both frequency and level sweep functions. Pulse signal generation is standard on the unit and can control common third-party USB power sensors for cable loss compensated sourcing.
